Features:
1.Used to cut Aluminum Profile -45° ~90°~45°.
2.Double head drived by motor.
3. Motion of head by imported linear bearing pair .
4.. Solid and Rigid structure , Safe and Reliable , High Precision , Large Range ,Efficiency and Easy Operation
Parameters
| Model | LJZ2-450x3700 |
| Voltage | 380V/50HZ |
| Power | 1.5KWx2 |
| Rotary Speed | 2850 rpm/min |
| Cutting Angle | -45° ~90°~45° |
| Cutting Width | 120mm |
| Cutting Height | 200mm |
| Cutting Length | 400mm to 3700mm |
| Dimension | 4500x1170x1400mm |
| Weight | 1400KGS |
Detailed Pictures
